weaving machines used for sale

4 MüLLER jacquard needle looms for labels and trimmings with woven soft selvedges, composed of: 1 MÜLLER type MVC2 200 14/36 768/448, year 1998, taffeta machine 1 MÜLLER type MVC 200 15/30, year 1995, satin machine 1 MÜLLER type MVC 200 20/20, year 1994, satin machine 1 MÜLLER type MVC 150 8/46, year 1991, satin machine

1 SULZER VAUPEL label rapier loom type G6500 S190 N8 J and EWM 80-175E, year 2008, weaving width 168 cm, BONAS electronic jacquard type ZL 2L-24, 2304 hooks, BONAS Series 800 controller, VAUPEL control type MCD-3, machine supplied with 8 IRO Stella G2 weft feeders

1 SULZER VAUPEL label rapier loom type G6500 S150 N8 J and EWM 80-135E, year 2006, weaving width 126 cm, STÄUBLI electronic jacquard type DX110, STÄUBLI JC6 controller, VAUPEL control type MCD-3, machine supplied with 8 IRO Stella G2 weft feeders

1 BENNINGER sectional warping machine type SUPERTRONIC, working width 220 cm, year 1989, machine supplied with 2 trolley creels type BEN-CREEL from the year 1999, each 640 spindles (8 stores x 40 columns x 2 sides), vertical gauge 240 mm, horizontal gauge 240 mm

1 BENNINGER sectional warping machine type BEN-ERGOTRONIC, working width 200 cm, year 1995, machine supplied with 2 trolley creels type BEN-CREEL, each 640 spindles (8 stores x 40 columns x 2 sides), vertical gauge 240 mm, horizontal gauge 240 mm

1 SUCKER MULLER high performance sizing machine for cotton warps year 1985, composed of: beam creel type ZA for 16 beams, device for feeding from sectional beam, 1st sizing unit type SD M1, roller width 2000 mm, double dip, double nip with pressure adjustment, 2nd sizing unit type SD M2, roller width 2000 mm, double dip, double nip with pressure adjustment, cylinder dryer type ZT-ZG, steam heated, total 8 cylinders (6 of these cylinders are teflonized), diameter 800 mm, beaming unit WN10, maximal beam pipe width 2700 mm, working width 2400 mm machine supplied with size kitchen

1 SUZUKI sample warper NAS130-W, year 1997, delivered in 1998, width 225 cm, drum perimeter 7 m, 10 colours standard creel (with 10 weft feeders) SUZUKI type RC8 rotational creel, year 1998, 8 colours (with 8 weft feeders), W type beaming with oiling device, high speed selector enabling warping speed of 1000 m/min, with PC and software for pattern design and machine control

1 MÜLLER air jet label loom MÜJET 2S type MBJL 2S 115, specification SPE5 1536/1152 T, year 10-2001, commissioned in 2002, tafeta machine, 8 colours, 740 rpm, MÜDATA 300, machine delivered with 3 weft feeders, 1 warp beam, 1 cloth roller, 20 thermal cutters

1 USTER warp tying machine type UMM, with frame width 200 cm

1 GENKINGER dobby changing trolley type FDCT, year 2002 carrying capacity 400 Kg

Three identical weaving machines used in the plastics industry are available. Working width: 1900mm, weft insertion: 8 colors. On-site inspection is possible. Individual sale is possible.

PICANOL OPTIMAX Rapier loom (GUID System )Year 2013, width 190 cm , Dobby Staubli Type: S3020 with 16 Levers, 4 Color with 4 Luna X2 Accumulator, Beam Diameter 1000, 4000 Lammel/Droppers, GROB Contact Bar, BEATCHING MOTION WITH CONTROL PANEL, 10 Healdframe, each machine with 1,5 Beam, Edge Cutting Leno, Warp Release system Electronik ELO. Best working condition

01 sets Picanol Air-Jet TERRY Weaving Loom, type OmniPlus SUMMUM- 340 YOC 2015, working width 340 cm, 6 weft colors Stäubli DOBBY STAUBLI – electron. take-up and warp let-off, max warp beam flange dia. 1,000 mm, off-loom take-up

01 sets Picanol Air-Jet Weaving Loom, type OmniPlus 6-P - 340 YOC 2001, working width 340 cm, 6 weft colors Stäubli cam motion 1661 (of 2006) – 6 shafts installed, Sumo motor, electron. take-up and warp let-off, max warp beam flange dia. 1,000 mm, off-loom take-up

A)01 Karl Mayer Direct Warper – ZM – SP 1700/1000 year 1997, working width 180 cm, Max. Beam Flange Diam. 1,016 mm with 01 Karl Mayer warping creel, H-type, 630 creeling positions Disc brakes, electr. stop motion, pitch 30 cm – adjustable abbot. 60-70 fractional beams (for direct warper and sizing) B)01 Karl Mayer Rotal Sizing machine, type ELC-O-TENS year 2000, with Pleva humidity and tension control, warp beam creel, for max. 16 warp beams Nom. working width 180 cm max. beam flange Ø 1,016 mm pneum. Brakes 1 sizing double trough Nom. working width 180 cm Pre-Wetting double dip and squeeze roller pair Cylinder Dryer 10 drying cylinder Ø 800 mm Partitioning Field Abt. 4.5 mtrs. Waxing device Beaming machine / headstock max. nom. working width 240 cm, max. beam flange Ø 1100 mm speed up to 140 m/min Beam Pressure Device Size kitchen turbo cooker,

3 sets used RAPIER LOOMS, make PICANOL, type GTM R 190 year 1985, working width 190 cm, 3 weft colors, Stäubli dobby 2232 – 12 levers installed, double whip roller, electron. Warp let-off max warp beam flange dia. 800 mm, off-loom take-up

02 sets used Picanol Rapier Weaving Machine, Optimax-4-R year 2008 (1) and 2010 (1), working width 220 cm, FF free flight rapiers with Staubli el. Dobby 2622 – 12 shafts ETU - On-loom take-up, EWL - el. Warp-let-off, ELSY leno selvedge device max. warp beam flanges 1,000 mm, double whip roller

01 set Picanol Air-Jet Weaving Looms, type OmniPlus 800 – 220-4R YOC 2010, working width 220 cm, 4 weft colors Stäubli electron. dobby 2881 – 16 shafts installed, Sumo motor, electron. take-up and warp let-off, max warp beam flange dia. 1,000 mm, off-loom take-up

DISPONIBLE 10 LOOMS FOR NARROW COMPLETED CREEL RUNNING CONDICTIONS

TYPE : G6200 S 190 N8 SP - SPECIAL EXECUTION FOR CARBON OR TECHICAL FABRIC WEAVING 8 COLOR, WITH STAUBLI DOBBY 2617 WW : 190CM ACCESSORIES : CREEL WITH 192 POSITIONS , BY CMG , YOC 2010 DUST SUCTION UNIT 4 FRAMES 4 PREWINDERS IRO ORION BATCHING MOTION
