THERMO FORMING MACHINE ILLIG RDM 37/10

machines for plastic / thermoforming machines / Thermo forming machines

Manufacturer: ILLIG

Model:RDM 37/10

Type of machine: THERMO FORMING MACHINE

item-No.: 162692640

Quantity: 0

Date: 01.03.2024

Year of manufacture: 1992

Operating hours: 41685

Location: Land-ch Switzerland

Price:


Your price suggestion:

Machine in stock:No

Seller-item-No.:91104.23

Technical specifications:
Rated power, kW: 11,3
Mold area, mm: 475 x 250
Max. film width, mm: 495
Min. film width, mm: 150
Max. feed length, mm: 280
Min. feed length, mm: 50
Max. drawing depth/negative, mm: 100
Number of cycles/min.-max.: 48
Consumption of air/cycle at 6 bar: 100 Nl (net-pressurized air)

Heat energy to be dissipated:
with top heating ca. 10 260 KJ/h
with top and bottom heating ca.: 17 715 KJ/h

Special equipment: Hollow floor facility available
Control cabinet: included
