used
Glue application machine with 2 rollers Mod. SC2R-1300 Year: 2006 Production: FIN s.r.l. Italy Main technical specification: Width of machining: 1300mm Maximum passage between rollers: 120 mm Diameter of rollers: 185mm Progress speed: 19m/min Net weight 390 kg Overall dimensions: 64 x 210 x 136cm Overall dimensions with case: 73 x 222 x 153cm 400 V, 50 Hz, 037 Kw Accurate and uniform application with any type of adhesive, excellent technical characteristics, For the high practicality, functionality and safety for the operator, set it at the at the top of the 2-roll glue application machines. Coating roller covered with acid-resistant rubber, ground and grooved, hard-wearing as they are Built with a rational layer of rubber, it is therefore possible to carry out 6-7 grinds. It is easy and quick to disassemble. Distribute, precisely and evenly on one or both sides ...
used
Bürkle glue application machine Type DAK 1300 Built in 1993 4 Roller Glue Dispensing Machine Machine for single and double-sided glue application Effective working width 1300 mm Roller length 1400 mm Frequency-controlled drive 6-30 m/min Motorized height adjustment via push button Passage height up to 80 mm 2 fluted application rollers diameter 240 mm 2 dosing rollers diameter 190 mm Rubber coating of the rollers in good condition With flushing device Nominal power 2.1 kW Dimensions approx. 2600 mm x 1900 mm Weight 1700 kg
used
Code: 0514 Brand: FMB - ITALY Model: BM 4/L - CE Standard Automatic edge bander for wood, Pvc, veneer, Abs, panels, joinery, furniture, bespoke furnishings, doors, kitchens and various other applications – CE Standard Technical data: Panel height 10–60 mm Max edge thickness 10 mm Min panel length 120 mm Min panel width 60 mm Glue tank capacity 2 kg Feed speed 14 mt/min Electric roller press lifting Composition: Gluing unit – Glue tank 2 kg – PVC shears End-trimming unit with 2 motors 0,5 Hp 12000 rpm – Cut inclination 0–5° Trimming unit with 2 motors 1,5 Hp 12000 rpm Bevelling unit with 2 motors 0,5 Hp 12000 rpm Space available for additional units Tilting sanding unit from –10° to +45° – Sanding is carried out using a straight or shaped pad which acts directly on the abrasive belt Oscillating belt Pneumatic belt tensioning Telescopic roller conveyor for s ...
used
Code: 0317 Brand: OSAMA Model: S4R-P - CE Standard Automatic 4 rollers gluing machine with 2 motors for vinyl glue (PVAC), urea glue (UF) and polyurethane glue, for various types of materials like MDF, chipboard, plywood, parquet, composite materials, plasterboards, furniture, panels, doors and various, building sector, sponges, mattresses, papermaking - CE Standard Technical data: Working width mm 1400 Working height mm 0-100 Work surface height mm 890 Spreading roller diameter mm 250 Overall dimensions mm 2450 x 1300 x 1600 h Weight kg 830
used
Code: 0197 Brand: CASADEI INDUSTRIA Model: K 30/10 HF - CE Standard Automatic edge bander for straight panels, with glue tank for wood, veneer, pvc, melamine, abs and various - CE Standard Technical data Automatic belt conveyor for panel feed - Speed 7 mt/min Panel height mm 10/45 Edge thickness up to 3 mm Gluing unit: Glue tank capacity kg 1,2 - Electronic temperature control Front and rear pneumatic end cutting unit with circular Vidia blades - Micrometric cutting depth adjustment -End cutting speed 9000 rpm - End cutting blade diameter 80 mm Upper and lower end trimming unit - Vidia cutters diameter 80 - Possibility of combined radius/chamfer cutters - End Trimming speed 9000 rpm Total power Kw 2,2 N° 3 suction ports diameter 60 mm Panel support roller conveyor Overall dimensions mm 2150 x 800 x 1200 h Weight kg 405
used
Code: 0510 Brand: BIESSE Model: POLYMAC SINGLE 89 - N - CE Standard Edgebander for straight, shaped, and round panels, for Pvc, Abs, veneer, and wood edges, for woodworking shops, custom furniture, furniture, kitchens, shelves, and various applications - CE Standard Features: Motorized feeder with adjustable speed Pneumatic trimming unit for trimming edged panels Digital electronic counter for setting the desired cutting length Work surface tilting from 0 to 45° Adjustable edge feed speed Technical Data: Edge height 10-60 mm Edge thickness 0,4-3 mm Min radius 20 mm Min panel length 300 mm Feed speed 2-18 mt/min Total power 4 Kw Compressed air 6 bar Overall dimensions mm 1700 x 950 x 1300 h Weight kg 350
used
TECHNICAL DATA: Maximum working width: 1300 mm 2 rolls: Ø 200 mm 2 wheels: Ø 170 mm Installed power: 1.5 HP EQUIPMENT: Adhesive container Roller Cleaning System
used
Code: 0688 Brand: FRAVOL Model: A 16/S Edgebander for straight and shaped panels, for wood edges, veneer, Pvc, plastic laminate, etc. Technical data: Edge height mm 10/60 Edge thickness mm 0,4 - 1,2 Min edging radius mm 20 Power Watt 2500 Shear for roll cutting Compressed air 5 atm Overall dimensions mm 1300 x 1000 x 1100 h Weight kg 260
used
Technical data: - Working height ¦ 950 mm - Pneumatic connection ¦ min. 6 bar - Machine length ¦ 4305 mm - Constant feed rate 8 m/min - Workpiece width min: - At workpiece thickness 8-22mm ¦ 70 mm - For workpiece thickness 23-40mm ¦ 120 mm Depending on the workpiece length - Workpiece protrusion ¦ 38 mm - Workpiece thickness ¦ 40 mm - Edge height max. = workpiece height ¦ + 5 mm - Edge material roll ¦ 0.3 - 3 mm - Edge cross-section max. - For PVC ¦ 135 mm² - For veneer ¦ 100 mm² - Roll diameter max. ¦ 830 mm - Strip edge material ¦ 0.4-3.0 mm - Edge cross-section max. - For strips ¦ 135 mm² Equipment: - Inlet ruler manually adjustable - Workpiece support ball sleeve - Manual chain conveyor central lubrication - Top roller pressure with toothed rubber rollers - Height adjustment manually - Joining milling unit 2x0.7 kW (40 mm milling cutter) - Standard ...
used
Key data: 3 mm, 60 mm, 4500 mm
SCM Olimpic K360 - Single-sided edge banding machine - Year of construction 2021 - Immediately available - Top condition
used
Key data: 3 mm, 60 mm, 4000 mm
SCM Olimpic K360 - Single-sided edge banding machine - Year of construction 2016 - Immediately available - Incl. replacement glue basin - Top condition
used
BIESSE Stream A / 6.0 Single-sided edge banding machine for attaching various edge materials (Melamine, PVC, ABS, Veneer, Wood) - Year of construction 2018 - Including air cushion table - Immediately available - Including dismantling and loading - Including additional replacement glue basins
used
Single-sided edge banding machine for machining of straight workpiece edges and for banding and post-processing of various edge materials in longitudinal and transverse passage. OVERVIEW OF THE UNIT CONFIGURATION: Electronic control POWER CONTROL PC 20+ PU top pressure rollers instead of rubber rollers Optimization of workpiece spacing Inlet ruler extension by 300mm with additional laminate overhang device JOINING MILLING UNIT 2 X 2.2 KW 200 HZ GLUING UNIT A12 with automatic edge retraction – Quickmelt APPLICATION UNIT – Standard application unit replaceable PU glue – Pressure zone with motorized adjustment QA 45 EVA application unit for all types of adhesives and quick changeovers CROSS-CUT UNIT CHAMFER/STRAIGHT 2 X 0.35 KW PNEUMATIC ADJUSTMENT CAPS CHAMFER/STRAIGHT PNEUMATIC 2-POINT ADJUSTMENT CAPS PRE-MILLING UNIT 2 X 0.55 KW counter-rotation – with PNEUMATIC 2- ...
used
Single-sided edge banding machine for machining of straight workpiece edges and for banding and post-processing of various edge materials in longitudinal and transverse passage. OVERVIEW OF THE UNIT CONFIGURATION: JOINING MILLING UNIT 2 X 2.2 KW 200 HZ GLUING UNIT A8 with workpiece preheating, fill level control, Quickmelt application unit, magazine and motorized pressure zone CROSS-CUT UNIT CHAMFER/STRAIGHT 2 X 0.18 KW PNEUMATIC ADJUSTMENT CAPS CHAMFER/STRAIGHT MULTI-STAGE MILLING UNIT MS 40 COUNTER ROTATION PNEUMATIC 2-POINT ADJUSTMENT SHAPE MILLING UNIT 1 X 0.35 KW WD 60; also for construction floors PNEUM. 2-POINT ADJUSTMENT RADIUS/CHAMFER MZ 40 MULTI-STAGE SCRAPER UNIT GLUE JOINT SCRAPER BLADE BUFFING UNIT Top pressure: PU rollers instead of standard rollers Release agent spray unit workpiece, leading and trailing edges; edge material Power Control PC 20+ Ele ...
used
Code: 0480 Brand: CASADEI INDUSTRIA Model: K 60 PM - CE Standard Automatic edge bander with trimming unit for panels, furniture, furnishings, kitchens, and various - Year 2024 - CE Standard Technical data: Min/max panel height 8–60 Edge thickness10 mm Min panel length 120 mm Min panel width 110 mm Panel feed speed 11 mt/min Panel support roller opening 500 mm Configuration: Infeed trimming unit : 2 diamond cutters diameter 60 mm 64 mm height - PLC-controlled work cycle - Adjustable material removal from 0 to 2 mm with digital display - HF motors, 200 Hz - 12000 rpm - 1,1 Kw each PLC-controlled logic operation - Full machine control - Electronic glue heating control - Automatic temperature standby Infrared lamp for preheating the panel after pre-milling Anti-adhesive liquid spray unit Glue tank - Tank capacity 2 kg - n° 7 electric heating elements Pressure rollers ...
used
Key data: 5 mm, 10 mm, 3160 mm
EBM edge banding machine KDP 111 SLK - built in 1991 -11.5 kW motor, banding from 0.8-5 mm, verst. Cross-cut knife (roll separation up to 3 mm) Rapid heating basin, HF cross-cut sawing unit, HF flush milling unit, HF chamfer or Radius milling unit, pull-out workpiece support, heated inlet ruler complete with 2-part sound insulation hood and central extraction - Good condition - Length approx. 3,160 mm Depth with roller plate approx. 1,230 mm Workpiece width, min. 90 mm Workpiece thickness, min. 10 mm Workpiece thickness, max. 50 mm Workpiece length, min. 260 mm -Operating instructions available
used
Aggregate equipment: - Joining milling unit 2 x 2.2 Kw 200 Hz - Gluing unit - Cross-cut unit chamfer/straight 2 x 0.35 Kw - Milling unit 2 x 0.55 Kw counter rotation - Grooving unit 1 x 3.5 Kw - Shape milling unit 2 x 0.35 Kw Wd 60 - Profile scraper blade with quick-change heads (R 1 and 2 mm) - Glue joint scraper blade - Buffing unit Other features: - Extended inlet ruler with program adjustment - Program adjustment pressure zone - Motorized adjustment upper pressure - PU top pressure rollers - Automatic edge retraction - Quickmelt application unit - Pneumatic 2-point adjustment caps - Pneumatic adjustment of the scraper blade - Program adjustment side buttons - Pneumatic 2-point adjustment, vertical sensing rollers - Release agent spray unit workpiece - Lubricant spray unit edge material - Cleaning agent spray unit - Axis adjustment for groove milling machi ...
used
Edge banding machine Brandt Highflex KDF 220 with jointing, corner copying and two Scraper blades. Very well automated. A video of the running machine can be sent on request. Edge thickness roll approx. 0.4 - 3mm, solid edge up to 6mm Workpiece height approx. 10 - 60mm Feed speed approx. 10m/min Noise protection hood Pull-out workpiece support Suction connection 1x120mm, 1x100mm, 3x80mm Easy-touch EC+ control for easy operation of the machine 4 programs can be saved. Machine in high-flex design, highly automated, change of edge from thin edge to thick edge via programs Aggregates: Extended inlet zone Chain conveyor central lubrication, pneumatic manual Quick-change glue basin device, currently one glue basin available Top pressure manual adjustment, PU rollers Infeed ruler manual adjustment with SIKO counter on chip removal Joint milling with slide ...
used
VersaPUR bag melter 7092486 year 18 overhauled and cleaned PUR processing from environmentally friendly 20-litre bags with film coating. Melt-on-demand function to reduce thermal stress and protect bonding properties. Pneumatic piston to squeeze the adhesive out of the container, almost eliminating residues. Retention of sufficient adhesive in the hopper to continue operation during bag changes.
used
VersaPUR bag melter 6080646 year 21 overhauled and cleaned PUR processing from environmentally friendly 20-litre bags with film coating. Melt-on-demand function to reduce thermal stress and protect bonding properties. Pneumatic piston to squeeze the adhesive out of the container, almost eliminating residues. Retention of sufficient adhesive in the hopper to continue operation during bag changes.
