Model
(Manufacturer: IMA)
CNC machining center IMA BIMA 310V 120/600 Year of production 2004 4 Axes With veneering - Dyna Poin BIMA 410 V preparation table Specifications: Editing area - in the X-direction without gluing: 6000 mm - in the X direction with gluing: 5000 mm - in the Y direction: 1300 mm - Y-direction with main spindle + tool Ø 20 mm: 1630 mm - in the Y direction with gluing: 1450 mm
IMA COATING MACHINE, MODEL GS EVOLUTION LAB Laboratory machine and for small production batches. Thanks to its interchangeable drum it can process a wide range of capacities (from 0.5 to 30 liters). MACHINE FEATURES three interchangeable baskets automated easy scale-up MANUFACTURING CHARACTERISTICS Minimum/maximum working capacity: 0.5÷30 l Pan diameter: 820 mm (ca) Pan mouth diameter: 300 mm (ca) ENERGY CONSUMPTION Pan motor power: 0.55 KW (ca) Process air delivery: 350 m³/h (ca) Power consumption for standard equipment: 14 kW (ca)
used
IMA COATING MACHINE, MODEL GS EVOLUTION LAB Laboratory machine and for small production batches. Thanks to its interchangeable drum it can process a wide range of capacities (from 0.5 to 30 liters). MACHINE FEATURES three interchangeable baskets automated easy scale-up MANUFACTURING CHARACTERISTICS Minimum/maximum working capacity: 0.5÷30 l Pan diameter: 820 mm (ca) Pan mouth diameter: 300 mm (ca) ENERGY CONSUMPTION Pan motor power: 0.55 KW (ca) Process air delivery: 350 m³/h (ca) Power consumption for standard equipment: 14 kW (ca)
Used Side loading case packer IMA CP6. Year of construction 2013 The machine has been modernized to meet the requirements of pharmaceutical product serialization
IMA C 80- A81 Blister and cartoning machine More information on request.
IMA CP28BA Min./Max. box size: 220 x 120 x 120 mm / 600 x 400 x 350 mm Overall dimensions (W x D x H): 5000 x 1850 x 1900 mm Speed: 8 cartons/minute Weight: 1500 kg Compressed air: 6 bar Installed power: 2.8 kW Complies with CE standards
IMA OVERWRAPPING MACHINE, MODEL BFB DIVISION 3711 Year of construction: 2016 Production reaches 110 cycles/min handling somewhat larger sized products. Changeover procedures are fast and easy, to avoid unwanted downtime. High quality individual or multiple over wrapping for regular product Complete with a device to lift the film-driving rollers during product elevation These machines enable the use of extremely thin films and avoid the film sliding around the product, thus obtaining the perfect over wrapping finish The equipment uses standard Siemens electrical components and a Siemens PLC. The steel frame is oil-tight and lubrication is by means of oil bath. TECHNICAL SPECIFICATIONS Electrical frequency: Hz 50 Operating voltage: Volt 380 Air pressure: bar 6 DIMENSIONS Net weight: Kg 1500 Length approx.: mm 6400 Width approx.: mm 1735 Height approx.: mm ...
used
IMA OVERWRAPPING MACHINE, MODEL BFB DIVISION 3711 Year of construction: 2016 Production reaches 110 cycles/min handling somewhat larger sized products. Changeover procedures are fast and easy, to avoid unwanted downtime. High quality individual or multiple over wrapping for regular product Complete with a device to lift the film-driving rollers during product elevation These machines enable the use of extremely thin films and avoid the film sliding around the product, thus obtaining the perfect over wrapping finish The equipment uses standard Siemens electrical components and a Siemens PLC. The steel frame is oil-tight and lubrication is by means of oil bath. TECHNICAL SPECIFICATIONS Electrical frequency: Hz 50 Operating voltage: Volt 380 Air pressure: bar 6 DIMENSIONS Net weight: Kg 1500 Length approx.: mm 6400 Width approx.: mm 1735 Height approx.: mm ...
IMA FILLING AND CLOSING MACHINE, MODEL STERIFILL SMART PWD Year of construction: 2017 IMA SMART PWD is able not only to process difficult powders accurately, but also to simultaneously dose, by vacuum-pressure, two different types of pharmaceutical products inside the same vial, with single 100% check-weighing. Speed: max. 100 pcs/min Available formats: 10R Transport system: Intermittent motion Highlights Possibility of dosing up to 2 different pharmaceutical powders in the same vial Vacuum-pressure powder filling system Advanced 100% IPC with speeds of up to 120 pcs/min Possible integration of a capping station Pick & place stoppering system Fit for isolation technology with possibility of wetting in place cRABS for powder containment Technical characteristics Standard voltage: 400 V, 50 Hz, 3ph + N + G Installed power: 19 kW
IMA BLISTERING MACHINE, MODEL C102 Year of construction: 2018 Machine for tray production with automatic product feeding, characterized by a balcony style structure which also allows a customization of the feeding area depending on the product to pack. the linear work flow of the material allows an easy forming material introduction each change-over despite its simplicity, it’s an ideal tray forming machine with attractive speed flexible for the packaging of syringes, ampoules, vials, small cosmetic products, solid forms etc. extremely simple to use for semi-skilled operators too PRODUCTION Cycle speed 15-40 cycles/minute Tray dimensions 30-138 mm (W) x 52-250 mm (L) x 3-25 mm (D) Vial blisters production 3 Blisters/Forming Step (Ampoules): 5 x 1ml 5 x 2ml 3 x ½ml 1 x ½ml
High-speed labeller for 2.25 ml Ypsomate Autoinjectors. The machine line consists of an automatic pallet management system for the autoinjectors packed on pallets in trays: a) Integrated Full Tray De-Palletizing with a first FANUC robot, which places the trays on a conveyor belt. On the same machine, the empty pallets are palletized with empty trays by a second FANUC robot. b) Machine where via the conveyor belt, trays transported with autoinjectors arrive at the next FANUC robot. This robot will pick up the autoinjectors in the laying position from the trays and put them upright into the feeder to machine c). The emptied trays will be transported back to machine a), where they will be picked up and put onto an empty pallet. c) Fully autom. rotary labelling machine IMA, type Sensitive Roto 720. Machine with two label dispensers for faster reel change (no downtime). Outp ...
Used bulk cartoner made by IMA model CP6. New 2013. Upgraded to the requirements of serialization of pharmaceutical products.
IMA VIALS LABELLING MACHINE, MODEL SENSITIVE 350 Year of construction: 2010 Labelling machine for vials and bottles. A simple design for effectively handling cylindrical containers. equipped with one side labelling head, for applying the label with high accuracy thanks to an appropriate spacing between the containers and an easy-to-regulate application group labelling unit is installed in the machine basement for direct access to the labelling reels supervision and monitoring of the process through a PLC with a user-friendly HMI TECHNICAL DATA Production details Bottle maximum height (mm): 220 Bottle diameter (mm): 16-78 Maximum output (pieces/minute): 350 Labels Label length (mm): 15-250 Label height (mm): 10-100 Label reel diameter (mm): 400 Label accuracy (mm): ±1 Electrical usage Standard voltage: 400 V – 50 Hz Installed power (kW): ...
IMA OVERWRAPPING MACHINE, MODEL AC60 Year of construction: 2005 Fully automatic single overwrapper, ideal for pharmaceutical products. Equipped with a high-speed stacking unit capable of stacking up to 225 layers/min. Maximum accessibility to all components due to the balcony design, cleaning and maintenance are also facilitated. scissor knife film transport by pincers transversal edge-sealing driven movement of bottom and lateral film folders reciprocating lateral sealing plates PRODUCTION CHARACTERISTICS Box sizes Min: 50x23x60 mm Max: 220/280x100x220 mm Length film Min: 100 mm Max: 450 mm Max speed 60/80 ppm Wrapping film cellophane PVC PE PP KRAFT ELECTRICAL DATA 208 V/3 phases
IMA LABELLING/TAMPER EVIDENT MACHINE, MODEL A 400 TE – NTF Year of construction: 2015 Ensures accurate and precise label application while reaching a high production speed when product protection from damage and tampering is needed. User-friendly, quick maintenance and easy to operate. PRODUCTION Maximum output: 400 cartons/minute Vignette label size (mm) Length: 15 – 60 Height: 10 – 60 Vignette reel diameter (mm) Up to 400 Tamper-evident label size (mm) Length: 15-35 Height: 15-35 Tamper-evident reel diameter (mm): Up to 400 Labelling accuracy (mm): ± 1 Carton dimensions A: 20 to 130 mm B: 12 to 100 mm C: 50 to 210 mm ELECTRICAL DETAILS Installed power (kW): 3.5 Standard voltage: 400 V – 50 Hz – 3PH + PE DIMENSIONS Size: 2345 x 2900 x 1265 mm (ca) Weight: 1,000 kg (ca)
IMA BFB K150 horizontal intermittent motion cartoning machine for blisters, etc. carton size range min. 20 x 12 x 50 mm (AxBxC), max. 85 x 60 x 190 mm, reverse tuck closure, GUK FA21/4 Cartonac 91 leaflet folder from stack, Laetus Argus 6012 bar code reader for carton and leaflet, electrics 380V/3PH/50Hz, machine floor space approx. 300 x 1300 mm (LxW), machine height approx. 1950 mm, machine net weight approx. 1500 kg, capacity up to 120 cartons per minute
CNC Machining Center IMA BIMA 610/V Type 140/600 Machine in CE design Travel range in X 7700 mm Travel range in Y 1900 mm Travel range in Z 440 mm Working range in X-direction with standard units 6000 mm Working range in Y-direction with standard units 1400 mm Max. clamping height from the upper edge of suction plate Z1 100 mm Z2 depending on equipment / application
Autom. cartoning machine incl. autom. bottle feeder (from turntable Ø 800 mm), blister feeder from magazine, leaflet feeder for pre-folded leaflets etc. PLC: IDEC.
HORIZONTAL CARTONING MACHINE IMA, MODEL A94 Year of construction: 2002 Fully automatic continuous motion horizontal cartoner for blisters, with balcony structure. Features: - Centrally adjustable product chain - Automatic blister infeed system - Siemens PLC - Argus Laetus coder - GUK FA 21/4 leaflet folder and inserter - Stainless Steel construction - Full interlocked guarding - Manuals, technical documentation and drawings in English and Polish Suitable box sizes: length 55mm to 210mm, width 25mm to 110mm, height 12mm to 85mm. Manufacturer's suggested maximum speed output of 320 cartons per minute (last run at 280 cartons per minute). Machine size: 5100mm L x 1650mm W x 2100mm H Approximate weight: 3500kg
IMA CARTONING MACHINE, MODEL K150C Year of manufacture: 1995 (overhaul: 2011) K150 is an accessible, reliable and efficient cartoner ensuring quiet running at high speed. Its carton prebreaking and opening system combined to extrapositive carton handling by multiple belts ensures best carton forming control. Its design allows fast access and easy cleaning. The machine is equipped with a feeding system for bottles, a feeding system for vials, a GUK Cartonac 81 FA21/ 4 leaflet feeder, IncJet printing and control unit, Antares Vision print control system. TECHNICAL DATA Frequency: 50 Hz Voltage: 380 volts Power: Kw 4,5 Weight: Kg 1500 Production characteristics: Min carton dimensions: mm 20 x 12 x 50 Max carton dimensions: mm 85 x 60 x 190 Max production: 150 cartons/min Pressure: 6 ATM The K150 can handle a wide range of product feeding groups (bottles, squeezable ...
IMA CARTONING MACHINE, MODEL FLEXA CSD Year of construction: 2009 Flexa is a high performing, reliable, efficient and modular cartoner. It offers product handling combined with fast changeovers, ensured by advanced computer-controlled technology. Offers the best ergonomics for access, changeover, cleaning and trouble shooting. It can handle the cartoning of bottles (both plastic and glass), cosmetics, jars, inhalers, ampoules, vials and syringes etc. Equipped with GUK leaflet folder. TECHNICAL DATA: Net weight: approx. Kg 1580 Length: mm 3650 Width: mm 1750 Height: mm 2000 Frequency: 50 Hz Voltage: 400 volts Current: A 23 Pressure: bar 6 Production characteristics: Production speed: 140 cartons/min Carton width: 26-50 mm Carton height: 26-50 mm Carton length: 93-120 mm Compressed air consumption: 134 NI/min Installed power: 5 Kw The cartoning cycle is complet ...
IMA CARTONING MACHINE, MODEL EASY Year of construction: 2006 EASY is an automatic intermittent motion cartoner designed and built for the insertion of single and multiple products inside a previously formed box. It also allows the insertion of service accessories, booklets, envelopes or flowpacks together with the products. TECHNICAL DATA Frequency: 50 Hz Voltage: 380 volts Production characteristics: Max production speed: cartons/min 80 Carton Length: mm 80 – 130 Carton Width: mm 60 – 115 Carton Height: mm 57 – 75 Blister length: mm 74 – 120 Blister Width: mm 50 – 69 Blister Height: mm 5.8 – 7.5 Leaflet (L x W): 160 x 38 mm EASY guarantees the integrity of the packages. The machine automatically checks all the packaging phases, indicating any anomalies on the display and, if necessary, stopping the machine to allow control. Equipped with an AK162 i ...
IMA SHRINKWRAPPER, MODEL MS450EA-T450 Year of construction: 2006 Automatic machine with alternating movements operating with reels of shrinkable film. The packages obtained are subsequently heat-shrunk by the tunnel placed at the exit of the shrinkwrapper. The machine is designed to pack single or bundled cases or products in pre-glued cartons or trays of standardized dimensions. TECHNICAL DATA Net weight: Kg 1500 Length: mm 3100 Width: mm 2100 Height: mm 1980 Production characteristics: Shutter conveyor belt dim. (LxW): 1760 x 110 mm Polyurethan conveyor belt dim. (LxW): 540 x 280 mm Tunnel dimension (LxWxH): 1500 x 1000 x 1720 mm Tunnel conveyor belt dim. (LxW): 1300 x 500 mm The product coming from the upstream line enters the belt that accompanies it up to the level layering area. The bundle, pushed forward, causes the unwinding of the film from the two reels and ...
The Swiftcheck is designed to feed and count any size, shape or quantity of tablets without change parts, and is the ideal unit to serve as a line monitoring machine to check the count accuracy of filled containers from the packing line. The system is simple to operate and easy to clean. Technical data: Length: mm 575 Width: mm 200 Height: mm 600 Designed for ease of operation and simple setting, the Swiftcheck incorporates a similar microprocessor package to that used on the high speed counting machines, achieving the same high level of accuracy and reliability. The basic unit comprises a stainless steel cabinet with integral micro processor control system, 5 litre product hopper and vibrator feed arrangement with variable vibration control, quick release twin-track feed tray and contact parts, stainless steel outlet funnel and clear plastic dust cover.
The T300 tablet press is a rotary press that compresses solids and is equipped with 40 punch stations. The exact characteristics of the press machine vary according to the type of punch chosen. Technical data: Length mm 1280 Width mm 865 Height mm 1850 Net weight Kg 1920 Power A 12 Frequency Hz 50 Voltage Volt 380 Productions characteristics: Machine speed 260,000 tablets / h Max. tablets diameter 13 mm Filling depth 2 – 16 mm Min. production 12,000 tablets/h Max production 300,000 tablets/h Mould external diameter 24.01 mm Mould height 22,22 mm The T300 is a rotary tablet press equipped with two pairs of pressure rollers, one for pre-compression, the other for main compression. The operator side of the press is mainly in the front part of the machine where the four manual wheels, the control elements and the console are located. The press is fed from the top, ...
C260 is the most compact deep draw thermoforming machine in his range keeping the maximum customisation that exactly meets the customer's production requirements. All this is possible thanks to the use of the IMA Safe technology which has developed robotized systems applied in the most critical areas: the product feeding area & the connection to the cartoner. Size changeover operations are rapid thanks to a reduced number of size parts. Technical data: Length mm 6000 Width mm 1530 Height mm 1850 Net weight Kg 2500 Frequency Hz 50 Voltage Volt 400 Production characteristics: Forming Depth 3 – 40 mm Production speed: up to 800 1-2 ml DIN ampoules/min up to 400 1 ml syringes/min Chiller dimensions 480 x 470 x 960 mm Film trolley dim. 860 x 800 x 1130 mm Additional format available 8 ampoules Format currently installed is for blister of 5 ampoules.
Insertion with tweezers; Feeding leaflet/brief leaflet; Feeding pots; Closure case; Exit with expulsion. Machine weight: kg. 2200 Compressed air consumption: Nl/min. 200 Pressure: 6 bar Total absorption installed: kW 3 CASES DIMENSIONS (MM): Minute: A = 20; B = 24; C/H (Low) = 40; High C/H: 50 Maximum: . : A = 120; B = 100; C/H (Low) = 100; C/H (High): 180; A + B = 200
Edge banding machine Manafacture: IMA Model: Molding edge banding machine Year of construction: 1997 Hot air unit for pre-glued edge material
Technical Details: - X axis working area: 5300 mm - Y axis working area: 1300 mm - Working Table Pod and Rail - Main Electrospindle power: 9 KW - Number of controlled axes: 5 axes - Total number of drilling spindles: 32 - Total number of tool changer positions: 8
