Hydr . Flat profile and bar steel shears with notching device and hole punching Specifications: - Flat steel shears cut up to 375 x 10 mm - 220 x 20 mm - Profile steel shears - cuts L-steel at 90° to 130 x 13 mm - Steel bar shears - cuts round steel up to 45 mm - Square steel up to 45 mm - Notching device - with square notching device 100 x 42 x 10 mm - Hole punch - punching force 600 KN - with stop table - Projection 300 mm - perforated in steel up to 28 mm Ø in 15 mm - or 34 mm Ø in 12 mm - manual length stop - Drive 400 V / 4 kW - Space requirement approx. W 600 x H 1550 x D 1500 mm - Weight approx. 1300 kg
pressure: 60 t punching cross-cut in cmm: 305 stroke: 55 mm : 625 mm : 0 - 100 mm : 1075 mm : 29 x 15 mm hole punching press: capacity (dia. x thick.): 57 x 8 mm : 5,5 kW : 1300 kg : 1600 x 700 x 1800 mm Some accessories are available with the machine. The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
round bar steel: 30 mm square edge steel: 25 mm L-beam: 60 x 8 mm hole diameter in sheet thickness: 20 x 15 mm hole punhing press: pressure: 40 t hole punching press: throat: 175 mm hole punching press: max. length of stroke: 32 mm total power requirement: 3,0 kW weight of the machine ca.: 0,62 t dimensions of the machine ca.: 0,9 x 0,8 x 1,3 m The data for this ad was created with ModulMWS - the software solution of LogoTech oHG.
used
Section Cutting - round bar: 50 mm - square bar: 50 mm - C amp; I profiles: up to 160 mm Notching - rectangular: 52 mm - material thickness: 13 mm Punching - 33 x 20 mm - 30 x 20 mm - 55 x 12 mm - 38 x 15 mm - bending cap: 250 x 20/10 mm Shearing Flatbar - 380 x 20 mm - 480 x 15 mm - angletrim: 120 x 15 mm Angle Cutting - at 90°: 150 x 15 mm - at 45°: 80 x 10 mm Punching pressure: 85 ton Max sheet thickness by punching + nibbling: 33 x 20 mm Max punching dia: 55 x 12 mm Length: 1830 mm Depth: 790 mm Height: 1920 mm Weight: 2620 kg
