Offer 24130 Specifications: - Drilling capacity into solid steel ST 60 32 mm - Drilling capacity GG 25 40 mm - Threading ST 60 M 27 - Drilling spindle holder MK 4 - Quill stroke 150 mm - 12 drilling spindle speeds 102 - 2000 rpm - 3 drill feeds 0.1 - 0.3 mm - min./ max. distance spindle – table 310 / 610 mm - Drilling radius min / max 380 / 1200 mm - Table height 720 mm - Table size 1200 x 500 mm - Drive 400 V / 2.0 / 2.4 kW - Space requirement approx. W 1200 x H 2800 x D 2300 mm - Weight approx. 1500 kg - with: - Tapping device - hydr. Columns + Boom Clamp - Coolant device - T – Vertical grooves on the rear side of the machine
Item condition: well-maintained Availability: immediately Volts: 380 Heart: 50 Table length (mm) approx.:1120 Table width (mm) approx. 255 Milling paths: longitudinal (mm) approx.: 750/ 850 transverse (mm) approx.: 400 vertical (mm) approx:400 Upper arm movement (mm) approx.: 570 Quill movement (mm) approx.: 130 Standard Accessories - Hardened and ground guide paths - Central lubrication system - Coolant device - Variator head rpm approx. 60-40,000 infinitely variable - Motor approx. 2.2 kW
