- CYPCUT - high-end CNC with German surface
- IPG - laser source
- Precitec Lightcutter - cutting head
- Interchangeable table
- 2 CCD cameras, 2 for indoor use, 1 x for control shuttle table
- 2 years warranty
-Stabilizer
- Air conditioning for control cabinet
- High-performance radiator
- Anti-collision protection
- Fast Cutting Mode
24 months warranty
Working area (mm) 4000 x 2000
Max. working height (mm) 100
Effective travel X axis (mm) 4050
Y axis (mm) 2050
Z axis (mm) 100
Position accuracy X axis (mm/m) ±0.03
Y axis (mm/m) ±0.03
Z axis (mm/m) ±0.01
Repeatability X axis (mm) ±0.01
Y axis (mm) ±0.01
Z axis (mm) ±0.005
Positioning speed X axis (m/min) 120
Y axis (m/min) 120
Z axis (m/min) 30
Acceleration: X-axis: 1.5G , Y-axis: 1.5G
Working table load 2000 kg
Table change in sec. 20
Max Cutting Heights – IPG Laser
4000 W 20 mm / steel - 16 mm / stainless steel
6000 W 25 mm / steel - 20 mm / stainless steel
8000 W 30 mm / steel - 25 mm / stainless steel
Thickness for good cutting quality Material
16 mm / steel - 14 mm / stainless steel
20 mm / steel - 16 mm / stainless steel
25 mm / steel - 20 mm / stainless steel
Connected load IPG 4/6/8 kW - 40/60/80 kw/h
Protection level IP54
Machine functions:
Mark
Film burning (removal of an existing oil layer by means of a laser)
Various piercing options
Y-joint generation
Fast Cut (cutting without piercing)
Fly Cut (cutting without piercing at constant speed) Different cutting
qualities selectable per contour Automatic and manual plate angle
determination
Sequential processing of several NC jobs Sequential processing of
several plates Laser pointer for starting point determination
Stop NC machining with the following options: Reverse to contour and
restart machining Manual movement of the axes and restart machining
Complex C2C (contour to contour) handling
