CNC Long Turning Automatics GILDEMEISTER GD 32-5A

metal working machines / lathes / CNC Long Turning Automatics
add to watchlist
send inquiry
print view
item-No.: 162731367 Quantity: 0 Date: 16.04.2025
Year of manufacture: 2004 Location: 87719 Mindelheim
Price: request quote
Manufacturer: Gildemeister
Model: GD 32-5A
Type of machine: CNC Long Turning Automatics
Description: CNC Long Turning Automatics Gildemeister GD 32-5A

used machine

Specifications:
Main spindle:
Max. turning diameter: 33 mm
Max. speed: 8000 1/min
Drive power: 5.5 kW
Drive power at 60% ED: 7.5 kW

Slide 1:
Carriage path Z1: 320 mm
Slide path X1: 50 mm
Carriage path Y1: 255 mm
Rapid traverse speed: 30 m/min
Ball screw diameter: 25 mm

Tool holder slide 1:
Number of tools
fixed with tool shank 16 x 16: 5 pieces

Slide 2:
Slide path X2: 165 mm
Carriage path Z2: 200 mm
Rapid traverse speed: 30 m/min
Ball screw diameter: 30 mm

Tool holder slide 2:
Number of stations for turret with integrated spindle: 8 pieces
Number of axially driven tools (integrated): 8 pieces

Coolant pan, approx.: 400l
Coolant pump, max. capacity: 80 l/min
Dimensions (LxWxH), approx.: 2460 x 1510 x 1750 mm

Equipment:
- CNC control Fanuc iT
- W745297 Workpiece unloading system
- IEMCA bar loading magazine
- 5-item tool carrier plate for carriage 1
- Electr. Interface and software for bar loading magazine
- Collet holder for main and pick-up spindle
- 2 double drill holders for rear machining support with cylinder
- Pick-up spindle workpiece pusher
seller offer No. resale WW12452
Machine in stock: Yes
Seller-item-No.: WW12452
