Four-sided planing machines SCM SUPERSET 23

wood working machines / planing machines / Four-sided planing machines

Manufacturer: SCM

Model:SUPERSET 23

Type of machine: Four-sided planing machines

item-No.: 124002086

Quantity: 0

Date: 31.01.2023

Year of manufacture:

Location: Land-it Italy

Price:


Your price suggestion:

Machine in stock:Yes

MULTI MOULDERS machine with 7 shafts type SCM SUPERSET 23 PLUS . with SLIDE and RETURN PIECES type MAHROS RP/4
second hand machine
CE mark : Yes
volt. 380/50
- Composition (7 shafts , 7 independent engines):
1° shaft : lower horiz . motor power Hp 7,5
2° shaft : right vertical . motor power Hp 7,5
3° shaft: left vertical (automatic). motor power Hp 7,5
4° shaft : upper horiz. motor power Hp 10
5° shaft : upper horiz. motor power Hp 10
6° shaft : lower horiz. motor power Hp 7,5
7° shaft : universal 360° . motor power Hp 10
grove table
inlet length mm. 2400
feed speed: from 5 to 35 mt./min
max. useful working width mm. 230
max. useful working height mm. 120
shaft diameter mm.40
automatic lubrication system
weight kgs. 4300

Inquiry

Machinery dealer?

Please remit optionally

Send wanted inquiry?

Copy to you?

Save input data

MULTI MOULDERS machine with 7 shafts type SCM SUPERSET 23 PLUS . with SLIDE and RETURN PIECES type MAHROS RP/4
second hand machine
CE mark : Yes
volt. 380/50
- Composition (7 shafts , 7 independent engines):
1° shaft : lower horiz . motor power Hp 7,5
2° shaft : right vertical . motor power Hp 7,5
3° shaft: left vertical (automatic). motor power Hp 7,5
4° shaft : upper horiz. motor power Hp 10
5° shaft : upper horiz. motor power Hp 10
6° shaft : lower horiz. motor power Hp 7,5
7° shaft : universal 360° . motor power Hp 10
grove table
inlet length mm. 2400
feed speed: from 5 to 35 mt./min
max. useful working width mm. 230
max. useful working height mm. 120
shaft diameter mm.40
automatic lubrication system
weight kgs. 4300
seller offer No. resale 124002086
