Technical data for the pallet racking system:
Shelving system: Stow
Type: Pal Rack NS
Technical data for the installation:
Number of rows of shelves: 01 pcs.
Shelf length: approx. 15,100 mm
Number of fields / row of shelves: 04 pcs á 3,600 mm
Number of levels plus floor level: 03 pcs.
Technical data on the volume:
Pallet spaces per field: 16 pcs.
Pallet spaces per row: 64 pcs.
Total pallet spaces: 64 pcs.
based on:
Loading aids: Euro pallet EN 13698-1
Dimensions: 1,200 x 800 x 150 mm
Total height incl. pallet: n.d.
Weight per pallet ( max. ): 389 kg
The scope of delivery includes:
05x Pallet racking stand, used
Material color: sendz. galvanized
Profile dimensions: 140 x 80 x 2.25 mm
Incl. cross and diagonal struts,
Footplates
The stands are pre-assembled
( screwed truss )
4,700 mm high
1,100 mm deep
24x pallet rack traverse, used
Material colour: RAL 2004 orange
Box profile: 120 x 50 mm
Truss type: PNB 0472
Agraffe: 4 HK (hook)
clear width: 3,600 mm
max. load per pair of trusses
1,558 kg at the same time. distributed load
48x locking pins, used
Version: complete. galvanized
To secure the longitudinal beams
against unintentional lifting
20x bolt anchors, new
Manafacture: Hilti
Type designation: HST2 M12x105/10
Design: carbon steel, galvanized
Approved for: cracked concrete
10x compensating plates, used
Version: complete. galvanized
to level the shelf stands, use the
be placed on uneven ground
01x Load signs
with information on field and specialist loads,
Manufacturer and commission number
Dimensions: 297 x 210 x 2 mm
Germany
26835 Neukamperfehn
