paper converting: slitter rewinders used for sale

For sale: Bragernes aut. coreless rewinder, year 1981, web width 1000 mm, Unwind dia. 1000 mm. Can make rolls from 5 m up to outside dia. 50 mm With web guide and tension control.Available: Now

Type: Super Lynx 800 built in 2001 Material width: max. 800 mm Material thickness: PET, OPP, aluminium and composite materials 12 – 200 μm Mech. Speed: 0 to 300 m/min.  Production speed depending on the material, Weight: approx. 2000 KG Maximum rewind diameter: 500 mm (400 kg) Maximum diameter of the nut roller: 800 mm Supply voltage 3 x 400 V 50 Hz Compressed air: dry 6-7 bar dry Noise: without extraction 75-80 dB With suction 85 dB Edge control of Air spindle: 70 / 76 / 152 Suction in the process

ELSNER V4-30 Roll Rewinder with MAF RP 750 Packaging Line – High-Performance, Fully Automated Solution Precision. Reliability. Efficiency. – A Complete Industrial Solution at an Unbeatable Price Looking for a powerful and reliable roll rewinder with an integrated packaging line? This ELSNER V4-30 Rewinder, combined with the MAF RP 750 roll packaging system, delivers seamless operation, high precision, and maximum efficiency—perfect for industrial roll processing and packaging. Location: Nuremberg, Stratus-PET GmbH Year Built: 1983 Condition: Excellent – Well-Maintained & Fully Operational
Price Options: €36,000 – ELSNER V4-30 Rewinder Only (Load on Truck) €45,000 – Complete Line: Rewinder + Packaging System (Ready to Ship) Position 1: ELSNER V4-30 Roll Rewinder – High-Performance & Precision Master Reel Capacity: 40 inches Product Roll Width: 12 to ...

S. No.: 999 0909 134 Equipment / Additional information: max. web width 400 mm easy operation via touch screen with full diagnostics unwinding max. roll diameter 600 mm electromagnetic brake, roll diameter controlled with ultrasound roll end detector electronically controlled web edge control with ultrasound sensor inspection table fixed splicing table with double web clamps adjustable splicing table with double web clamps rotary longitudinal cutter with 6 knives (scissor cut) as insert winding servo-controlled 2 interchangeable spindles 76 mm internal and external winding total and circulation counter, label and meter counter speed up to 300 m/min connection values electrical 240V; 1 phase, 1 N, 1 PE /13 AMP air: 6 bar

Max web width : 330mm Unwind roll max diameter : 700mm Speed : up to 35 meters/min Unwinder with ultrasonic web guide 1 rotary flexo station 1 lamination unit Semi rotary die cutting station Magnetic cylinder of semi-rotary die : Z-120. Slitter Rewinder

Duplex Slitter rewinder Web width: 1400mm Unwind diameter: 800mm Rewind diameter: 500mm Maximum speed: 300m/min Integral unwind station with 76mm and 152mm air shafts Hydraulic roll lift and disc brake on unwind BST CLS Pro web guide unit for edge and line guiding Tension control via load cell mounted we path roller Infeed driven nip unit 3 motor dc drive system with analogue drive control Razor in grooved roller slitting station with several knife holders Edge trim removal fan Duplex cantilevered rewind with differential slip adapters Full width lay on roll assemblies with pneumatic application Side opening door for roll off loading with guard inter locks Off loading roll capstan unit Control panel with digital display and digital counter Electrical diagrams

Max width: 1400 mm Machine speed: 600m/min Material width: 1400 mm Max. reel diameter unwinder: 1100 mm Rewinder type: double shaft Max reel diameter rewinder: 610 mm Max. unwinding tension: 785 N Max. contact pressure 5,00 Bar Max. rewinding tension: 500 N Max. diferential tention: 5,00 Bar Max. linear tention: 0,500 N/mm Laser positioning Pneumatic rotary knifes Automatic knife positioning system Friction rewinding shafts Pneumatic tension roller Web controlling systems Turning rack for unloading of ready rolls Materials: Films, Laminates, Paper, Aluminium

cutting plotter OKI/Graphtec FC 8600-130; Cutting surface 1372mmx50m; Max. Roll width 1529mm, min.50mm; Max. Cutting force 600g in 48 steps. Cuttin plotter OKI/Graphtec FC 8600-130; cutting area 1372mmx50m; max.roll width 1529mm, min.50mm; max.cutting force 600g in 48 steps.

Qty. 3 Second-hand winders Mfc.: Maxson Built: 1997 Roll width: max. 1,700 mm, min. 450 mm Maximum roll diameter: 1,650 mm The width of the core is: 70, 76, 120, 152, 300 mm

Special offer: for sale by owner 1600 mm German slitter rewinder suitable for paper & film can be shown in operation equipped with circular knives web guide with photocell materials: paper, films dancing roller for control of web tension unwinder diam 1000 mm rewinder: double rewinder diam. 600 mm included also: antistatic bars rollers with needles for perforation Special price, dismantling & loading included in the price Machine offered subject to unsold

Working width: 1400 mm Masch. Item no.: 1116 with 5 pairs of knives 1x Retractor

Special offer: 1000 mm Schiavi used duplex slitter-rewinder very compact machine- it needs very little sapce and can be put next to the wall can be shown in operation FILM: unwinder diam. 1000 mm rewinder double web guide with photocell rewinder: easy removing of the finished rolls thanks to cantilevered rolls Special price for quick sale Machine offered subject to unsold Best regards Joanna Laskowicz Flexo

for sale by owner, special price for quick sale: used Titan duplex slitter rewinder 1200 mm in operation worked with film & paper unwinder diam. 1000 mm, shafts 76 & 152 mm rewinder: double shafts on rewinder: 76 mm film: youtu.be/T949u6BQRLU Special price for quick sale only- we need space Machine offered subject to unsold

2014 Smag Label Inspection Machine – Slitter Rewinder 350 mm working width Slitting Rewinding Tube Scan digital Inspection Camera Web Guide Label Inspection with or without slitting Manufacturer: SMAG GRAPHIQUE Type: 825 Year of manufacturing: 2014 Web width: 350 mm Mechanical Speed: 120m/min Rewinding Spindles: 25 / 40 / 50 / 76 mm Machine is located in Western Europe Please contact PP Machinery Team for more information or an inspection

Shaftless Unwind Monomatic Typ MD 107 (150 mm core diameter) FIFE side edge control max. roller diameter 1,070 mm Web tension control device Multiple breaking device Trimming station Cutting accuracy +/-0.2 mm Automatic angle adjustment Automatic sheet length adjustment without gear change Working width up to 1250 mm min. Working width 600 mm, cutting length from 550 to 1500 mm Materials from 60 g/sqm to 150 g/sqm (unwinder max. 120 g/m2) Ionisation device Waste ejection station Shingled delivery Belt delivery extended to the end of the stack Counting device Pile delivery with jogger max. mechanical output 300 m/min Cerutti embossing station - suitable for surface embossing (steel - paper 1 : 1.85) Embossing calender output max. 250 m/min

Hobema sheeter with print: 3 flexo colors: in operation width min- maxx. 200-1050 mm 2 unwinders, max. diam. of the reel 900 mm special cylinder for receiving sheets, suitable for paper & tissue 3 longitudinal cutting knves gears:38,40,43,45,50,52,60,63,70,75 cm Machine offered subject to unsold over 20 years of experience in the industry high quality machines of renown European producers we also buy for stock warehouses in European Union

Special offer: Lemu 1050 mm semiautomatic slitter rewinder reel diam on unwind: up to 1100 mm can be shown in operation rewind diam up to 180 mm, if more needed we will check if possible rewinder: cores: cores: 76 mm and 12,7 min width of the reel 15 mm print of the stripe at the end of the reel automatic stop after achieving particular diameter of the reel machine offered subject to unsold Best regards

machine can be used for spare parts The VITS-ROTOCUT S is a cross cutter with rotary knives for fixed sheet lengths and variable web widths Fixed size cutting length: 625 mm Maximum web width 1000 mm Minimum web width: 8 pages 280 mm – 16 pages 400 mm. Range of substance weights: 35 g/m2 to 200 g/m2 Production speed: 8.75m/sec – at 625 mm cut-off = 50,400 cph

Slitter /Unwinder Manufacturer: Proslit Model: DUO 1350 SL Year : 2007 Machine Number: 135 SL With Printvision/ apollo II AVT Precision Camera Complete with all available spares and manuals

Working width: 1300 mm
