Order No. 6762
TECHNICAL DATA
- max width of the workpiece 220mm
- max height of the workpiece 130mm
- 4 spindles:
1) horizontal bottom 220mm 5.5kW
2) vertical right 130mm
3) vertical left 130mm; (2 and 3 spindles) 11kW
4) horizontal top 220mm 7.5kW
- all adjustable spindles up / down, right / left
- diameter of the spindles 40mm
- from the top 4 introducing, drawing, toothed rollers
- from above, 1 pulling roller, rubber
- at the bottom, a pulling shaft, rubber
- feed on cardan shafts
- smooth regulation of the feed speed
- 1.5kW feed motor
- lifting motor 0.25kW
- electric adjustment of the planing thickness
- length of the introductory top 1970mm
- central lubrication
- diameter of the extraction connector 3x120mm, 140mm
- locked in the cabin
- dimensions length / width / height 3350x1400x1430mm
- weight about 1500 kg
- German production
- unpainted
- used planer, very good condition
Net price: PLN 49900
Net price: EUR 10617
Net price, calculated at the rate of 4.70 PLN / EUR
(with greater fluctuations in the rate, the price may change)
Poland
