4 Roll plate bending machine dual initial pinch MG Italy 2000X6mm Mode CNC EASYCOM 4-AXIS NEW MACHINE serial no. 25072 Capacity: -Width of plate: 2000 mm -Thickness plate roll 6 mm -Plate pre-bend 4 mm Rolls -useful width mm. 2050 -Top roll mm. 160 - Lower roll mm. 140 Configuration installed: hardened rollers, surface smooth finishing for all kind of plates and stainless steel Prebend process in manual and automatic full rounding no-flat plate ends Conical plate rolling cones and reducers hydraulic control dual initial pinch Driven rolls rotation hydraulic powered with axial gear unit plate dragging and forming . Console electric CNC with centralized commands joysticks , 4-axis position programming and readout. CNC controller interface touch screen 15”, 4 axis teach-in programming mode, infinite memory storage for automatic plate roll. On screen digital po ...
Plate bending machine 3 ROLL HYDRAULIC MODEL 3000 X 40 MM - YEAR 1997 PLATE BENDING ROLL PLANETARY DESIGN PYRAMID DUAL PRE-PINCH Nameplate Bending capacity -Plate width : 3000 mm -Rolling plate thickness: 40 mm -Prebend thickness: 30 mm --- minimum rolling ID 550 mm depending on plate thickness and width Rolls dimensions: -Useful length 3100 mm -top roll D 450 mm -side rolls D 410 mm Accessories installed: Central upper support hydraulic control to hold the plate formed into large diameters Side arm hydraulic to support the large diameter being formed Conical bending attachment with hydraulic control of the angle setting for cone rolling, cone bending stopper hardened pad swing-down on the drop-end of the machine. Technical d ...
4 ROLL HYDRAULIC DUAL PRE-PINCH 3000x15 MM PLATE BENDING MACHINE NEW Brand MG model M3015 -Width of plate 3000 mm -Thickness of plate rolling 15 mm -Thickness of plate pre-bend 12 mm minimum bending diameter ID 350 mm Rolls dimensions: -Surface length mm. 3100 -Top roll mm. 290 -pinch roll mm. 270 -Power electric 10 Hp Technical data: -rolls hardened surface high resistance -variable rolling speed -Powered driven hydraulic rolls rotation -conical bending attachment roller type -calibration system re-rolling welded shells -deflection pinch pressure adjustable upon the thickness -overload protect complete safe operation of the machine. -control console on wheels with electric joysticks commands -position readout digital display for rolling memorize and repeat -safety and emergency systems installed -manuals and schematics along with the machine
Profile Bending machine Model AR360 -Year 2004 MG brand made in Italy OUTPUT SHAFTS 360 MM Capacity as per the original bending chart here enclosed Configuration installed with the machine -Pyramid dual pinch side rolls independent hydraulic positioning bending and pre-bending performance -The 3 shafts driven with hydraulic motor and gear unit individual on each roll -Synchronized speed automatic hydraulic control between the 3 rotating shafts -hydraulic traction tool to roll HEB_INP_UPN bending on hard-side. -Lateral correctors left/right hydraulic operated in 3 directions Tooling with the machine -Set of rollers for pipe: 6” and 12” -Set of rollers with adjustable opening width up to 400 mm ( for all the profiles bending easy way and hard way ) -Set of rings to increase the rollers opening width up to 500 mm ( for all the symmetric profiles b ...
Capacity plate width up to 3000 mm thickness 22 mm plate prebend 18 mm dual prepinch technical data: -length of rolls 3100 mm -top roll dia. 350mm -lower roll dia. 330mm -Hydraulic power unit with 20Hp motor -Electric supply Vac 400/50 – 480/60 Configuration complete: -Hardened surface of the 4 rolls -Conical plate bend hydraulic attachment. -hydraulic power driven rolls rotation with gear unit axial each -Synchronized hydraulic power dragging . -front open drop-end to remove closed shells. -Calibration re-rolling feature for welded shells Safety configuration in compliance. Control console electric commands with digital readout Predisposed ready to connect nr. 1 central hydraulic support for large dia. nr. 1 side arm hydraulic to hold in place think plate sheet being formed
Specifications: Working length: 4100 mm Max. bending power: 10.0 mm Bend: 8.0 mm Diameter upper roller: 310 mm Diameter of lower rollers: 285 mm Hardened rollers hydraulic snap roller bearing Conical bending device Control panel with digital display CE mark Dimensions (length x width x height)): approx. 5100 x 1250 x 1400 mm Weight: approx. 6.2 tons Condition: very good, almost mint condition The seller is not liable for typographical or data transmission errors. The machine is appropriate for its age in terms of appearance, technology and wear; used machines are sold without any warranty.
Specifications: Working width: 1050 mm Max. bending power: 100.0 mm Max. bend: 80.0 mm Diameter upper roller: 530 mm Diameter of side rollers: 530 mm Conical bending device by inclined position of the two side rollers Mobile control panel with digital display Engine power: 37 kW Hydraulic Safety Chucks CE mark Net weight: approx. 16 tons Auxiliary: 2. Roller set : Diameter upper roller: 360 mm Diameter of side rollers: 360 mm
Three-roller calender brand MG 3000 x 200 mm. Year 2006
3-roll hydraulic with dual pre-pinch planetary configuration. new to complete, 45 days from order. -Plate width 3000 mm -Capacity rolling plate thickness 50 mm -Pre-pinch plate thickness 40 mm Machine configuration and accessories installed: -useful surface length on the rolls 3100 mm -upper roll size 480 mm -lower rolls size 440 mm -Digital position readouts. -Hardening treatment of the 3 rolls. -3 rolls driven hydraulic motorized with independent axial gear box on each roll. -Conical plate bending attachment with tiltable lower rolls hydraulic. -CE quality certification, Made in Italy manufacturing. -Service manuals and operation instruction manuals. -Hydraulic diagrams -Electric & electronic schematics with parts list. -Set of service tools for maintenance. -Electric power installed 50Hp. -3 phase voltage to be specified Warranty 12 months. ...
Sheet thickness: 10,00 mm Bending length: 2050 mm Number of rolls: 4 Make MG 10 mm Type MH 2010 B Year 2009 4 walzen rundbiege plate roll blechrundbiege mg Sheet thickness (mm) T = 10 mm Bending length (mm) L = 2.050 Number of rolls Pre = 6 mm Top roll = 210 2 rolls driven Digital read out Hardened rolls 55 Hrc Fully hydraulic CE Saftety
Sheet thickness: 10,00 mm Bending length: 3100 mm Number of rolls: 4 Make MG 10 mm Type MH 308 B Year 2006 4 roll hydraulic plate bender mg blechrundbiege Sheet thickness (mm)T = 10 mm Bending length (mm)L = 3.100 mm Number of rolls 4 roll Pre bend = 6 mm Top rol = 230 mm Lower rol = 220 incl. Hydr. side support incl. CNC Control
Sheet thickness: 10,00 mm Bending length: 3100 mm Number of rolls: 4 Make MG 10 mm Type MH 308 B Year 2006 4 roll hydraulic plate bender mg blechrundbiege Sheet thickness (mm)T = 10 mm Bending length (mm)L = 3.100 mm Number of rolls 4 roll Pre bend = 6 mm Top rol = 230 mm Lower rol = 220 incl. Hydr. side support incl. CNC Control
Sheet thickness: 2,00 mm Bending length: 1050 mm Number of rolls: 2 SPECIFICATIONS Controll MG CNC Hydraulic / Mechanical Hyrdaulic 3 or 4 roll 2 Urethan Maximum sheet thickness 2 mm Bending length 1050 mm Top Roll Ø 100 mm Bottom Roll Ø 300 mm Power 5.5 kW
Sheet thickness: 10,00 mm Bending length: 2050 mm Number of rolls: 4 Make MG 10 mm Type MH 2010 B Year 2009 4 walzen rundbiege plate roll blechrundbiege mg Sheet thickness (mm) T = 10 mm Bending length (mm) L = 2.050 Number of rolls Pre = 6 mm Top roll = 210 2 rolls driven Digital read out Hardened rolls 55 Hrc Fully hydraulic CE Saftety
