Manufacturer:
Biesse Italy, Rover 22 CNC Machining Center Built in 2001 SN 07498 Workspace 4 axes X-axis 3060 mm Y-axis 1080 mm Z-axis 155 mm 6 consoles with 18 vaccum suction holder 4 pneumatic bakelite rods for lifting the plate Vertical electric spindle 7.5 kW with automatic tool change, ISO 30 cone Automatic tool change 7 positions on the working head Drill head with 20 spindles arranged as follows: 7 vertical in X-axis 7 permeable to Y-axis 4 horizontal in X-axis 2 horizontal in Y-axis Groove saw 120mm Safety tread mats 110 m3 / h vacuum pump CE marked Weight 3500 Kg Technical information subject to reservation
Masterwood Italy CNC Ventilation Center for Door and Window Production Type Woodmaster ATLAS Built in 2000 SN 00120018 for the processing of solid wood and panel material, etc. Working strokes of the axles: X Axis 3900mm Y Axis 1785mm Z- Axis 630mm Workspace X Axis 3500mm Y Axis 1210mm Z- Axis 210mm Max speed of axles 60-50-20m/min 6 edition consoles Workpiece clamping device Electric main spindle with ISO 30 intake 6.8 kW 24,000rpm Saw unit integrated in the work unit Automatic change of tools 18 positions Numerical control SINCRO with industrial PC and keyboard Safety tread mats Vaccum Pump Total required power 27 Kw Care pressure 6-7 atm Compressed air consumption per arebit cycle 200-300Nl/min Suction speed 25-30m/sec Air consumption 5000m3/h 400 V/ 50 Hz Weight 4500 Kg Technical information subject to reservation
BIESSE - Multi-spindle drilling machine Model BEAVER Year 1982 Manufacture Biesse S.p.A Italy S/N 312/82 Technical data 1 horizontal drilling unit, 21 spindles 2 vertical drilling units, 2x10 spindles, pitch 32 mm horizontal Drilling motor 2.2 kW Vertical drill motor 2 x 1.5 kW Spindle speed 2800 rpm Blade dimensions 10x1.5 mm Operating pressure 0> 6 MPa 7 pcs. pneumatic answers with kSsi control levers Weight 865 kg L x W X H 280cm x 150cm x 150cm
Double-sided fully automatic hydraulic cutting - milling - drilling machine PADE NST double-sided fully automatic hydraulic cutting - milling - drilling machine Production of chairs, tables, frames, and furniture parts Max work length 2100 mm Tilt-10° â +45° Rotation-10° â +50° 2 saw blades diameter 400 mm 2 drilling heads left, right can be rotated through 360 °, 8 spindle cross-shaped grid M2fi2 2 additional horizontal drilling heads from behind can be rotated by 360 °, 8 spindle cross-shaped grid 2 milling spindles bore wave 30 mm 1 motor for longitudinal adjustment of 1.5 kW 2 Saegemotore 2.2 kW 4 boring Motors 2.2 kW
HUNDEGGER K2 450 – 5 axes TOP 1 a maintained Year of manufacture 2004 • Type: 450 • Colour: RAL 5012 (blue) • Length of wood: 8 m / 7 m shelf • Catchment 5.37 m • Feed cross conveyor 5-strand 2.2 m horizontal • Pull-out wooden shelf • Under-table swivel cross-cut saw • Block disposal by box • Universal milling machine 5-axis o Roller milling cutter o Finger cutter o Dovetail cutter • Combined support for vertical tools o Finger milling machine 1 o Finger milling machine 2 • Combined support for horizontally working tools o Drilling rig swivel 2.2 kW • Marking and labeling device • Pneumatic beam turning station • 6-arm side table plant available at the end of 2025. Sale of the entire used joinery system as inspected ex site without warranty and guarantee. Payment of 100% of the gross purchase price immediately upon receipt of t ...
HUNDEGGER K2i 650 TOP 1 a maintained Year of construction 2017 • Machining cross-sections 300 x 650 mm • Frame length 13.56 m • Fully automatic timber feeding • Feed roller conveyor • Feed and feed cross conveyors • Under-table swivel cross-cut saw 11 kW • Universal milling unit 5-axis (UF5) o Roller milling cutter o Finger cutter o Dovetail cutter • Combined support for vertical tools o 2x vertical finger tiller 5.5 kW o 2x Drilling rig 2.2 kW o 1x Drilling rig 3 kW • Combined support for horizontally working tools o 1x Drilling rig 2.2 kW - drilling direction horizontal o 1x drilling rig swivelling 45° (3.0 kW) o 1x Slitting device 7.5 kW • Turret milling unit - vertical from above • Longitudinal and transverse groove milling machine • Rear marking device (stop side) • Front marking device (operator-side) • Marking and labeling de ...
Weeke ABD 150 Automatic Drilling and Dowel Insertion Brand: Weeke Type: ABD150 Year of construction 2013 Machine Number: 0-253-05-5352 Description: CNC-controlled duel drilling and driving machine Workpiece Dimensions: X-Axis: Y-axis: Z-axis: Stroke in the middle: Field of work: Positioning: X-Axis: Y-axis: Z-axis: Stops: Support table with front and back stops 6 workpiece supports can be freely positioned over the entire X-length with scale Pneumatically operated center stop, manual control via pressure switch 5 Vertical pressure cylinde, manual positioning Vacuum clamping for sensitive surfaces 10 vacuum suction cups freely to position over total length (115140100 mm) 2 vacuum cups (12575100 mm) 1 vacuum suction cup for shablone Vacuum pump: 40m³/hour Aggregates: Horizontal drilling unit with 1 spindle Dowel station (32 mm distan ...
Process: horizontal drilling - injecting glue - driving dowels1 drilling and doweling unit, freely programmableWorkpiece dimensions:Length min/max: 20 / 1250 mmWidth min/max: 50 / 800 mmThickness min/ max: 10 / 60 mmZ-axis manually adjustableDrilling depth manually adjustableCenter stop pneumatically lowerable4 vertical pushersDouble diaphragm pump 1:1Dowels: 8 mm x 30 mm, 8 mm x 35 mmControl: Powercontrol PC85T with Woodwop software
panel thickness: min 10mm, max 50 mmmax panel dimensions X : 3000 mm / Y : 900 mm min panel dimensions X : 300 mm / Y : 90 mm Feed speed : 20 m/minDrilling motor 2,2 kWspeed : 4,460 r/minvertical drilling spindles 86 horizontal drilling spindles, 2 x 2 in X direction, 1 x 2 in Y directiongrooving saw in X direction, diameter 125 mm
Hardware drilling and recessing machine, with multi-spindle headTable mountedMotor 1,1 kWFence left and right, 1,5 m. long
Max drilling depth 150 mmMax drilling length 310 mmHeading 270 x 90 mmHead rotation +/- 45°Min/max height door/window 600/1000 mmWorktable dimensions 420 x 60 mmTilt adjustment work table +/- 45°Motor chain 2,2 kWFront mechanical pusherAutomatic chain lubrication pump
Scheer Type DB 5 dowel hole drilling machine for precise and fast drilling of dowel holes (horizontal and vertical) in solid wood and panel materials. The machine is ideal for series production in furniture construction as well as for precise joints in interior design. Includes a comprehensive range of dowel drill bits., drilling spindles: 21, division: 32 mm, passage width: max. 1.000 mm, Pivot: pneumatic
Code: 0097 Brand: VITAP Model: ALFA 35 T - CE Standard Semi-automatic multiple boring machine with 35 spindles for furniture, kitchens, bathroom furniture, custom-made furniture, panels - CE Standard Technical data N° 35 spindles with quick coupling Centre distance between each spindle mm 32 Centre distance between first and last spindle mm 1088 Max depth of hole mm 70 Board dimensions mm 1454 x 590 Spindle rotations per minute 2800 Motor power Hp 3 Turret with 6 different depth positions Side fence Horizontal/vertical 45 degree pneumatic tilting head Metric bar 3000 mm with stops Fence for 45 degrees frames Operating pressure 6- 8 atm Overall dimensions mm 1590 x 860 x 1140 h Weight kg 454
Carpentry machine Hundegger k2 625 5 axis year 2003
1 used and very well maintained double cross-cut saw, manufacturer DE PAUW, built in 1998, lengths up to 9 m can be cut left and right in different inclinations. The machine is perfect for nail truss construction, frame timber construction, solar technology, wooden substructures and much more. incl. a driven roller conveyor in front of the system, with all available saw blades. The waste slides into the middle of the plant by an inclination plate and is conveyed there by means of a vibrating trough. At call. 5 t crane is available in the hall for dismantling. Sale as seen from the location. Self-dismantling. At call.
Dowel hole drilling device: pitch 16, 22, 25, 32; Drilling depth: 150 mm; Slotted hole length: 250 mm; Height adjustment range: 145 mm; Motor power: 1.5kW; Speed: 3000 rpm; Extraction connection: 100 mm; Machine length: 1280 mm; Machine width: 960 mm; Weight: 160 kg;
Dowel hole drilling device: no; Drilling depth: 150 mm; Elongated hole length: 180 mm; Height adjustment range: 145 mm; Motor power: 1.5kW; Speed: 3000 rpm; Extraction connection: 100 mm; Machine length: 1280 mm; Machine width: 960 mm; Weight: 240 kg; Solid slotted hole drilling machine with 2 lever controls.
Dowel hole drilling device: pitch 16, 22, 25, 32; Drilling depth: 145 mm; Elongated hole length: 240 mm; Height adjustment range: 135 mm; Motor power: 1.5kW; Speed: 2800 rpm; Extraction connection: 100 mm; Machine length: 1280 mm; Machine width: 960 mm; Weight: 250 kg; Solid slotted hole drill with a lever operation.
dowel hole drill device: division 16, 22 25, 32; max depth of the slot: 145 mm; max length of the slot: 240 mm; height adjustment: 135 mm; motor power: 1,5kW; speed: 2800 U/min; suction connection: 100 mm; machine length: 1280 mm; machine width: 960 mm; weight: 300 kg;
devel device: yes, 16, 22 25, 32; boring depht: 145 mm; boring length: 200 mm; height adjustment: 135 mm; motor power: 1,5kW; speed: 1500 / 3000 U/min; suction connection: 100 mm; machine length: 1280 mm; machine width: 960 mm; weight: 300 kg;
Dowel hole drilling device: pitch 16, 22, 25, 32; Drilling depth: 145 mm; Elongated hole length: 240 mm; Height adjustment range: 135 mm; Motor power: 1.3 / 1.8 kW; Speed: 1400 / 2800 rpm; Hold-down: manual; Extraction connection: 100 mm; Machine length: 1280 mm; Machine width: 960 mm; Weight: 300 kg;
Dowel hole drilling device: pitch 16, 22, 25, 32; Drilling depth: 180 mm; Elongated hole length: 240 mm; Height adjustment range: 160 mm; Motor power: 2.2 kW; Speed: 3000 rpm; Extraction connection: 100 mm; Machine length: 1280 mm; Machine width: 960 mm; Weight: 260 kg; Work table can be rotated by 60 degrees on both sidesSimple operation via one-hand lever for fast and precise workDrill head mounted on double guideClamp stops allow easy and quick adjustment of the drill head runHeight adjustment of the drill head via handwheel with numerical
Number of Spindles: 9; Drill pitch: 32mm; Power consumption: 2.2kW;
Number of spindles for row of holes: 15; Drill pitch: 32mm; Power consumption: 2.2kW; Drilling unit: adjustable in depth; Fitting drill head adapter: Drilling pattern Hettich; Hole row drill head: 15 drill bits;
Power: 750W/230V; Drilling capacity steel: 11mm diameter; Speed range: 100 †3000 rpm; Speed levels: infinitely variable; Spindle holder: B16; Drilling stroke: 60 mm; Spindle projection: 235mm; Table size: 290 x 290 mm; Quick-release chuck: 1 - 13 mm; Weight: 51 kg;
MAW BEV electric pneumatic cup band drilling machine for drilling cup bands or fittings., Support table: 300 x 37 cm, Engine: 1.6 kW, engine: 1,6 kW
Drilling depth vertical: 45 mm, horizontal: 120 mm, Working width: 720 mm, working width: 820 mm, Max. passage: 45 mm, Max throughput: 120 mm
Foot operation., Engine: 1.1 kW // 2,700 rpm.
CNC machining center SCM Routech R 3000 for processing plate material with automatic loading (vacuum destacker) and outlet. Special price for self-dismantling and self-collection., Workspace: 2,600 x 1,250mm, X-axis: 2.700 mm, Y axis: 1.600 mm, Z-axis: 250 mm, Spindle motor: 7,5 kW, feed: Max. 38 m/min, Video: On demand
Vitap Alfa35T dowel hole drilling machine for precise and fast drilling of dowel holes (horizontal and vertical) in solid wood and panel materials. The machine is ideal for series production in furniture construction and for precise joints in interior design., drilling spindles: 35, division: 32 mm, Spindle distance: max. 1,090 mm, drilling depth: adjustable up to approx. 65 mm, Pivot: pneumatic
